pxe 自动化安装系统 1.需求公司机房需要reinstall os 2.pxe原理2.1 原理与概念事实上把PXE称作是一种引导方式而不是安装方式似乎更加准确， PXE(Pre-boot Execution Environment)是由Intel设计的协议， 它可以使计算机通过网络启动， 但是有一个前提条件是计算机的网卡必须具有引导功能， 这个网卡中要有一个PXE客户端。 当计算机POST自检成功以后，BIOS把网卡中ROM的PXE客户端调入内存执行， PXE客户端通过网络中的DHCP服务器获取一个IP地址， 拿到IP地址以后PXE继续引导计算机与网络中的TFTP客户端建立连接， 从而从TFTP服务器中获取开机引导文件之后请求并下载安装需要的文件。 在这个过程中需要一台服务器来提供启动文件、安装文件、 以及安装过程中的自动应答文件等 2.2 pxe工作流程图原理介绍 Client向PXE Server上的DHCP发送IP地址请求消息，DHCP检测Client是否合法（主要是检测Client的网卡MAC地址），如果合法则返回Client的IP地址，同时将启动文件pxelinux.0的位置信息一并传送给Client Client向PXE Server上的TFTP发送获取pxelinux.0请求消息，TFTP接收到消息之后再向Client发送pxelinux.0大小信息，试探Client是否满意，当TFTP收到Client发回的同意大小信息之后，正式向Client发送pxelinux.0 Client执行接收到的pxelinux.0文件 Client向TFTP Server发送针对本机的配置信息文件（在TFTP服务的pxelinux.cfg目录下，这是系统菜单文件，格式和isolinux.cfg格式一样，功能也是类似），TFTP将配置文件发回Client，继而Client根据配置文件执行后续操作。 Client向TFTP发送Linux内核请求信息，TFTP接收到消息之后将内核文件发送给Client Client向TFTP发送根文件请求信息，TFTP接收到消息之后返回Linux根文件系统 Client启动Linux内核 Client下载安装源文件，读取自动化安装脚本 3 cobbler3.1 cobbler工作流程 client裸机配置了从网络启动后，开机后会广播包请求DHCP服务器 （cobbler server）发送其分配好的一个IP DHCP服务器（cobbler server）收到请求后发送responese，包括其ip地址 client裸机拿到ip后再向cobbler server发送请求OS引导文件的请求 cobbler server告诉裸机OS引导文件的名字和TFTP server的ip和 port client裸机通过上面告知的TFTP server地址通信，下载引导文件 client裸机执行执行该引导文件，确定加载信息，选择要安装的os， 期间会再向cobbler server请求kickstart文件和os image cobbler server发送请求的kickstart和os iamge client裸机加载kickstart文件 client裸机接收os image，安装该os image 3.3 Cobbler集成的服务PXE服务支持 DHCP服务管理 DNS服务管理(可选bind,dnsmasq) 电源管理 Kickstart服务支持 YUM仓库管理 TFTP(PXE启动时需要) Apache(提供kickstart的安装源，并提供定制化的kickstart配置) 3.4 配置目录配置文件目录： /etc/cobbler /etc/cobbler/settings : cobbler 主配置文件 /etc/cobbler/iso/: iso模板配置文件 /etc/cobbler/pxe: pxe模板文件 /etc/cobbler/power: 电源配置文件 /etc/cobbler/user.conf: web服务授权配置文件 /etc/cobbler/users.digest: web访问的用户名密码配置文件 /etc/cobbler/dhcp.template : dhcp服务器的的配置末班 /etc/cobbler/dnsmasq.template : dns服务器的配置模板 /etc/cobbler/tftpd.template : tftp服务的配置模板 /etc/cobbler/modules.conf : 模块的配置文件 数据目录： /var/lib/cobbler/config/: 用于存放distros，system，profiles 等信 息配置文件 /var/lib/cobbler/triggers/: 用于存放用户定义的cobbler命令 /var/lib/cobbler/kickstart/: 默认存放kickstart文件 /var/lib/cobbler/loaders/: 存放各种引导程序 镜像目录 /var/www/cobbler/ks_mirror/: 导入的发行版系统的所有数据 /var/www/cobbler/images/ : 导入发行版的kernel和initrd镜像用于 远程网络启动 /var/www/cobbler/repo_mirror/: yum 仓库存储目录 日志目录： /var/log/cobbler/installing: 客户端安装日志 /var/log/cobbler/cobbler.log : cobbler日志 3.5 命令介绍cobbler commands介绍 cobbler check 核对当前设置是否有问题 cobbler list 列出所有的cobbler元素 cobbler report 列出元素的详细信息 cobbler sync 同步配置到数据目录,更改配置最好都要执行下 cobbler reposync 同步yum仓库 cobbler distro 查看导入的发行版系统信息 cobbler system 查看添加的系统信息 cobbler profile 查看配置信息 3.6 /etc/cobbler/settings中重要的参数设置default_password_crypted: "$1$gEc7ilpP$pg5iSOj/mlxTxEslhRvyp/" manage_dhcp：1 manage_tftpd：1 pxe_just_once：1 next_server：< tftp服务器的 IP 地址> server： 4. cobbler install4.1 系统信息[root@cobbler ~]# getenforce Disabled [root@cobbler ~]# systemctl status firewalld.service ● firewalld.service - firewalld - dynamic firewall daemon Loaded: loaded (/usr/lib/systemd/system/firewalld.service; disabled; vendor preset: enabled) Active: inactive (dead) Docs: man:firewalld(1) [root@cobbler ~]# cat /etc/redhat-release CentOS Linux release 7.5.1804 (Core) [root@cobbler ~]# ip r default via 10.0.153.1 dev eth0 proto static metric 100 10.0.153.1 dev eth0 proto static scope link metric 100 10.0.153.116 dev eth0 proto kernel scope link src 10.0.153.116 metric 100 192.168.122.0/24 dev virbr0 proto kernel scope link src 192.168.122.1 [root@cobbler ~]# hostname cobbler 4.1.1 ks文件ks.cfg文件组成大致分为3段 命令段 键盘类型，语言，安装方式等系统的配置，有必选项和可选项，如果缺少某项必选项，安装时会中断并提示用户选择此项的选项 软件包段 %packages @groupname：指定安装的包组 package_name：指定安装的包 -package_name：指定不安装的包 在安装过程中默认安装的软件包，安装软件时会自动分析依赖关系。 脚本段(可选) %pre:安装系统前执行的命令或脚本(由于只依赖于启动镜像，支持的命令很少) %post:安装系统后执行的命令或脚本(基本支持所有命令) 关键字 含义 install 告知安装程序，这是一次全新安装，而不是升级upgrade。 url --url=" " 通过FTP或HTTP从远程服务器上的安装树中安装。url --url="http://10.0.153.118/CentOS-7/"url --url ftp://:@/ nfs 从指定的NFS服务器安装。nfs --server=nfsserver.example.com --dir=/tmp/install-tree text｜graphical tesxt：使用文本模式安装。 graphical：在图形模式下根据kickstart执行安装，默认该选项 lang 设置在安装过程中使用的语言以及系统的缺省语言。lang en_US.UTF-8 keyboard 设置系统键盘类型。keyboard us zerombr 清除mbr引导信息。 bootloader 系统引导相关配置。bootloader --location=mbr --driveorder=sda --append="crashkernel=auto rhgb quiet"--location=,指定引导记录被写入的位置.有效的值如下:mbr(缺省),partition(在包含内核的分区的第一个扇区安装引导装载程序)或none(不安装引导装载程序)。--driveorder,指定在BIOS引导顺序中居首的驱动器。--append=,指定内核参数.要指定多个参数,使用空格分隔它们。 network 为通过网络的kickstart安装以及所安装的系统配置联网信息。network --bootproto=dhcp --device=eth0 --onboot=yes --noipv6 --hostname=CentOS6--bootproto=[dhcp/bootp/static]中的一种，缺省值是dhcp。bootp和dhcp被认为是相同的。static方法要求在kickstart文件里输入所有的网络信息。network --bootproto=static --ip=10.0.0.100 --netmask=255.255.255.0 --gateway=10.0.0.2 --nameserver=10.0.0.2请注意所有配置信息都必须在一行上指定,不能使用反斜线来换行。--ip=,要安装的机器的IP地址.--gateway=,IP地址格式的默认网关.--netmask=,安装的系统的子网掩码.--hostname=,安装的系统的主机名.--onboot=,是否在引导时启用该设备.--noipv6=,禁用此设备的IPv6.--nameserver=,配置dns解析. timezone 设置系统时区。timezone --utc Asia/Shanghai authconfig 系统认证信息。authconfig --enableshadow --passalgo=sha512设置密码加密方式为sha512 启用shadow文件。 rootpw root密码 clearpart 清空分区。clearpart --all --initlabel--all 从系统中清除所有分区，--initlable 初始化磁盘标签 part 磁盘分区。part /boot --fstype=ext4 --asprimary --size=200 centos7 是--fstype=xfspart swap --size=1024part / --fstype=ext4 --grow --asprimary --size=200--fstype=,为分区设置文件系统类型.有效的类型为ext2,ext3,swap和vfat。--asprimary,强迫把分区分配为主分区,否则提示分区失败。--size=,以MB为单位的分区最小值.在此处指定一个整数值,如500.不要在数字后面加MB。--grow,告诉分区使用所有可用空间(若有),或使用设置的最大值。 firstboot 负责协助配置redhat一些重要的信息。firstboot --disable selinux 关闭selinux。selinux --disabled firewall 关闭防火墙。firewall --disabled logging 设置日志级别。logging --level=info reboot 设定安装完成后重启,此选项必须存在，不然kickstart显示一条消息，并等待用户按任意键后才重新引导，也可以选择halt关机。 4.2 配置yum源curl -o /etc/yum.repos.d/CentOS-Base.repo http://mirrors.aliyun.com/repo/Centos-7.repo curl -o /etc/yum.repos.d/epel.repo http://mirrors.aliyun.com/repo/epel-7.repo yum makecache fast 4.3 此次使用docker部署常规部署参考 https://www.cnblogs.com/linuxliu/p/7668048.html 4.3.1 构建镜像FROM centos:7.2.1511 MAINTAINER 595265578@qq.com RUN yum -y install epel-release vim net-tools RUN yum -y install httpd tftp cobbler cobbler-web dhcp xinetd syslinux pykickstart bind && yum clean all RUN (cd /lib/systemd/system/sysinit.target.wants/; for i in *; \ do [ $i == systemd-tmpfiles-setup.service ] || rm -f $i; done); \ rm -f /lib/systemd/system/multi-user.target.wants/*;\ rm -f /etc/systemd/system/*.wants/*;\ rm -f /lib/systemd/system/local-fs.target.wants/*; \ rm -f /lib/systemd/system/sockets.target.wants/*udev*; \ rm -f /lib/systemd/system/sockets.target.wants/*initctl*; \ rm -f /lib/systemd/system/basic.target.wants/*;\ rm -f /lib/systemd/system/anaconda.target.wants/*; VOLUME [ "/sys/fs/cgroup" ] RUN systemctl enable cobblerd;systemctl enable httpd;systemctl enable dhcpd RUN sed -i -e 's/\(^.*disable.*=\) yes/\1 no/' /etc/xinetd.d/tftp RUN touch /etc/xinetd.d/rsync EXPOSE 69 EXPOSE 80 EXPOSE 443 EXPOSE 25151 CMD ["/sbin/init"] 4.3.2 builddocker build . -t cobbler:1.0 4.3.3 运行镜像启动容器前我们要先修改配置文件settings和dhcp.template，下文的10.0.153.118为docker宿主机的IP地址。 将容器内部settings dhcp.template文件拷贝至/opt 目录settings文件中需要修改的内容为：server: 192.168.101.100 #cobbler的服务器地址 next_server: 10.0.153.118 #tftp服务器地址 manage_dhcp: 1 #dhcpg管理设置为1,启用dhcp dhcp.template文件中需要修改的内容为： subnet 10.0.153.118 netmask 255.255.255.0 { #修改网段 option routers 10.0.153.1; #指定网关 option domain-name-servers 10.0.153.118; #指定dns option subnet-mask 255.255.255.0; #指定子网掩码 range dynamic-bootp 10.0.153.120 10.0.153.200; #指定地址池 修改完成后保存文件，并使用如下命令启动容器：docker run \ -d \ --privileged \ --net host \ -v /sys/fs/cgroup:/sys/fs/cgroup:ro \ -v /etc/selinux:/etc/selinux \ -v /opt/settings:/etc/cobbler/settings \ -v /opt/dhcp.template:/etc/cobbler/dhcp.template \ -p 69:69 \ -p 80:80 \ -p 443:443 \ -p 25151:25151 \ --name cobbler1.0 cobbler:1.0 4.3.4 打开浏览器，确认cobbler_web可以访问账号和密码 cobbler/cobbler4.3.5 上传镜像vmware挂在iso镜像系统执行命令mount /dev/cdrom /mnt 拷贝镜像到容器内docker cp /mnt cobbler1.0:/opt/iso7 出现如上提示说明上传完成，之后点击Configuration模块的Distros，检查刚刚上传的镜像。4.3.6 ks文件服务器密码123456配置方法 修改settings文件 default_password_crypted[root@cobbler cobbler]# cat settings |grep pass # what install (root) password is set up for those # The simplest way to change the password is to run # openssl passwd -1 default_password_crypted: "$1$random-p$mzxQ/Sx848sXgvfwJCoZM0" # boot menu. Adding a password to the boot menus templates ldap_search_passwd: '' # This setting is also used by the code that supports using Spacewalk/Satellite users/passwords # URL will be passed directly to the kickstarting system, thus bypassing [root@cobbler cobbler]# openssl passwd -1 -salt 'random-phrase-here' '123456' $1$random-p$mzxQ/Sx848sXgvfwJCoZM0 ks文件模版 install url --url=$tree text lang en_US.UTF-8 keyboard us zerombr bootloader --location=mbr --driveorder=sda --append="crashkernel=auto rhgb quiet" #Network information $SNIPPET('network_config') #network --bootproto=dhcp --device=eth0 --onboot=yes --noipv6 --hostname=CentOS7 timezone --utc Asia/Shanghai authconfig --enableshadow --passalgo=sha512 rootpw --iscrypted $default_password_crypted clearpart --all --initlabel part /boot --asprimary --fstype="ext4" --size=200 part / --fstype="ext4" --grow --size=1 firstboot --disable selinux --disabled firewall --disabled logging --level=info reboot %pre $SNIPPET('log_ks_pre') $SNIPPET('kickstart_start') $SNIPPET('pre_install_network_config') # Enable installation monitoring $SNIPPET('pre_anamon') %end %packages @^minimal @compat-libraries @core @debugging @development bash-completion chrony dos2unix kexec-tools lrzsz nmap sysstat telnet tree vim wget net-tools %end %post systemctl disable postfix.service curl -o /etc/yum.repos.d/CentOS-Base.repo http://mirrors.aliyun.com/repo/Centos-7.repo curl -o /etc/yum.repos.d/epel.repo http://mirrors.aliyun.com/repo/epel-7.repo %end 5 使用koan实现重新安装系统5.1 在客户端安装koan[root@localhost ~]# rpm -ivh http://dl.fedoraproject.org/pub/epel/7/x86_64/e/epel-release-7-10.noarch.rpm 如何不能使用 请参考上面的阿里云源即可 curl -o /etc/yum.repos.d/CentOS-Base.repo http://mirrors.aliyun.com/repo/Centos-7.repo curl -o /etc/yum.repos.d/epel.repo http://mirrors.aliyun.com/repo/epel-7.repo [root@localhost ~]# yum install koan -y 5.1 查看cobbler上的配置文件1 [root@localhost ~]# koan --server=10.0.153.118 --list=profiles 2 - looking for Cobbler at http://10.0.0.101:80/cobbler_api 3 centos7-x86_64 重新安装客户端系统[root@localhost ~]# koan --replace-self --server=10.0.153.118 --profile=centos7-x86_64 重启系统后会自动重装系统6 通过dhcp 识别mac地址 自动安装需要关闭vmware dhcp服务 新创建的虚拟机为桥接模式cobbler配置[root@cobbler ~]# egrep -v "^#|^$" /etc/cobbler/settings --- allow_duplicate_hostnames: 0 allow_duplicate_ips: 0 allow_duplicate_macs: 0 allow_dynamic_settings: 0 anamon_enabled: 0 authn_pam_service: "login" auth_token_expiration: 3600 build_reporting_enabled: 0 build_reporting_sender: "" build_reporting_email: [ 'root@localhost' ] build_reporting_smtp_server: "localhost" build_reporting_subject: "" build_reporting_ignorelist: [ "" ] cheetah_import_whitelist: - "random" - "re" - "time" createrepo_flags: "-c cache -s sha" default_kickstart: /var/lib/cobbler/kickstarts/default.ks default_name_servers: [] default_ownership: - "admin" default_password_crypted: "$1$random-p$mzxQ/Sx848sXgvfwJCoZM0" default_template_type: "cheetah" default_virt_bridge: xenbr0 default_virt_file_size: 5 default_virt_ram: 512 default_virt_type: xenpv enable_gpxe: 0 enable_menu: 1 func_auto_setup: 0 func_master: overlord.example.org http_port: 80 kernel_options: ksdevice: bootif lang: ' ' text: ~ kernel_options_s390x: RUNKS: 1 ramdisk_size: 40000 root: /dev/ram0 ro: ~ ip: off vnc: ~ ldap_server: "ldap.example.com" ldap_base_dn: "DC=example,DC=com" ldap_port: 389 ldap_tls: 1 ldap_anonymous_bind: 1 ldap_search_bind_dn: '' ldap_search_passwd: '' ldap_search_prefix: 'uid=' ldap_tls_cacertfile: '' ldap_tls_keyfile: '' ldap_tls_certfile: '' mgmt_classes: [] mgmt_parameters: from_cobbler: 1 puppet_auto_setup: 0 sign_puppet_certs_automatically: 0 puppetca_path: "/usr/bin/puppet" remove_old_puppet_certs_automatically: 0 manage_dhcp: 1 manage_dns: 0 bind_chroot_path: "" bind_master: 127.0.0.1 manage_genders: 0 bind_manage_ipmi: 0 manage_tftpd: 1 manage_rsync: 0 manage_forward_zones: [] manage_reverse_zones: [] next_server: 10.0.153.118 power_management_default_type: 'ipmitool' power_template_dir: "/etc/cobbler/power" pxe_just_once: 1 pxe_template_dir: "/etc/cobbler/pxe" consoles: "/var/consoles" redhat_management_type: "off" redhat_management_server: "xmlrpc.rhn.redhat.com" redhat_management_key: "" redhat_management_permissive: 0 register_new_installs: 0 reposync_flags: "-l -n -d" restart_dns: 1 restart_dhcp: 1 run_install_triggers: 1 scm_track_enabled: 0 scm_track_mode: "git" server: 10.0.153.118 client_use_localhost: 0 client_use_https: 0 snippetsdir: /var/lib/cobbler/snippets template_remote_kickstarts: 0 virt_auto_boot: 1 webdir: /var/www/cobbler xmlrpc_port: 25151 yum_post_install_mirror: 1 yum_distro_priority: 1 yumdownloader_flags: "--resolve" serializer_pretty_json: 0 replicate_rsync_options: "-avzH" replicate_repo_rsync_options: "-avzH" always_write_dhcp_entries: 0 proxy_url_ext: "" proxy_url_int: "" [root@cobbler ~]# egrep -v "^#|^$" /etc/cobbler/dhcp.template ddns-update-style interim; allow booting; allow bootp; ignore client-updates; set vendorclass = option vendor-class-identifier; option pxe-system-type code 93 = unsigned integer 16; subnet 10.0.153.0 netmask 255.255.255.0 { option routers 10.0.153.1; option domain-name-servers 10.0.153.118; option subnet-mask 255.255.255.0; range dynamic-bootp 10.0.153.120 10.0.153.200; default-lease-time 21600; max-lease-time 43200; next-server $next_server; class "pxeclients" { match if substring (option vendor-class-identifier, 0, 9) = "PXEClient"; if option pxe-system-type = 00:02 { filename "ia64/elilo.efi"; } else if option pxe-system-type = 00:06 { filename "grub/grub-x86.efi"; } else if option pxe-system-type = 00:07 { filename "grub/grub-x86_64.efi"; } else if option pxe-system-type = 00:09 { filename "grub/grub-x86_64.efi"; } else { filename "pxelinux.0"; } } } ## group could be subnet if your dhcp tags line up with your subnets ## or really any valid dhcpd.conf construct ... if you only use the ## default dhcp tag in cobbler, the group block can be deleted for a ## flat configuration group { #for mac in $dhcp_tags[$dhcp_tag].keys(): #set iface = $dhcp_tags[$dhcp_tag][$mac] host $iface.name { #if $iface.interface_type == "infiniband": option dhcp-client-identifier = $mac; #else hardware ethernet $mac; #end if #if $iface.ip_address: fixed-address $iface.ip_address; #end if #if $iface.hostname: option host-name "$iface.hostname"; #end if #if $iface.netmask: option subnet-mask $iface.netmask; #end if #if $iface.gateway: option routers $iface.gateway; #end if #if $iface.enable_gpxe: if exists user-class and option user-class = "gPXE" { filename "http://$cobbler_server/cblr/svc/op/gpxe/system/$iface.owner"; } else if exists user-class and option user-class = "iPXE" { filename "http://$cobbler_server/cblr/svc/op/gpxe/system/$iface.owner"; } else { filename "undionly.kpxe"; } #else filename "$iface.filename"; #end if ## Cobbler defaults to $next_server, but some users ## may like to use $iface.system.server for proxied setups next-server $next_server; ## next-server $iface.next_server; } #end for } cobbler docker 打开tftp 服务 dhcp服务systemctl start tftp dhcpd配置好mac地址以下仅供参考 常规部署4.3.1 install cobblervim /etc/yum.conf 打开keepcache缓存改为1 yum -y install httpd dhcp tftp python-ctypes cobbler xinetd cobbler-web 4.3.2 start cobblersystemctl start httpd systemctl enable httpd systemctl start cobblerd.service systemctl enable cobblerd.service 4.3.3 cobbler check[root@cobbler ~]# cobbler check The following are potential configuration items that you may want to fix: 1 : The 'server' field in /etc/cobbler/settings must be set to something other than localhost, or kickstarting features will not work. This should be a resolvable hostname or IP for the boot server as reachable by all machines that will use it. 2 : For PXE to be functional, the 'next_server' field in /etc/cobbler/settings must be set to something other than 127.0.0.1, and should match the IP of the boot server on the PXE network. 3 : change 'disable' to 'no' in /etc/xinetd.d/tftp 4 : Some network boot-loaders are missing from /var/lib/cobbler/loaders. If you only want to handle x86/x86_64 netbooting, you may ensure that you have installed a *recent* version of the syslinux package installed and can ignore this message entirely. Files in this directory, should you want to support all architectures, should include pxelinux.0, menu.c32, elilo.efi, and yaboot. 5 : enable and start rsyncd.service with systemctl 6 : debmirror package is not installed, it will be required to manage debian deployments and repositories 7 : The default password used by the sample templates for newly installed machines (default_password_crypted in /etc/cobbler/settings) is still set to 'cobbler' and should be changed, try: "openssl passwd -1 -salt 'random-phrase-here' 'your-password-here'" to generate new one 8 : fencing tools were not found, and are required to use the (optional) power management features. install cman or fence-agents to use them Restart cobblerd and then run 'cobbler sync' to apply changes. 按照提示一个一个的解决问题：sed -i 's/^server: 127.0.0.1/server: 10.0.153.116/' /etc/cobbler/settings # 修改server的ip地址为本机ip sed -i 's/^next_server: 127.0.0.1/next_server: 10.0.153.116/' /etc/cobbler/settings # TFTP Server 的IP地址 service tftp { socket_type = dgram protocol = udp wait = yes user = root server = /usr/sbin/in.tftpd server_args = -s /var/lib/tftpboot disable = no # 修改为no per_source = 11 cps = 100 2 flags = IPv4 } [root@localhost ~]# cobbler get-loaders # 下载缺失的文件 task started: 2017-10-15_113824_get_loaders task started (id=Download Bootloader Content, time=Sun Oct 15 11:38:24 2017) downloading https://cobbler.github.io/loaders/README to /var/lib/cobbler/loaders/README downloading https://cobbler.github.io/loaders/COPYING.elilo to /var/lib/cobbler/loaders/COPYING.elilo downloading https://cobbler.github.io/loaders/COPYING.yaboot to /var/lib/cobbler/loaders/COPYING.yaboot downloading https://cobbler.github.io/loaders/COPYING.syslinux to /var/lib/cobbler/loaders/COPYING.syslinux downloading https://cobbler.github.io/loaders/elilo-3.8-ia64.efi to /var/lib/cobbler/loaders/elilo-ia64.efi downloading https://cobbler.github.io/loaders/yaboot-1.3.17 to /var/lib/cobbler/loaders/yaboot downloading https://cobbler.github.io/loaders/pxelinux.0-3.86 to /var/lib/cobbler/loaders/pxelinux.0 downloading https://cobbler.github.io/loaders/menu.c32-3.86 to /var/lib/cobbler/loaders/menu.c32 downloading https://cobbler.github.io/loaders/grub-0.97-x86.efi to /var/lib/cobbler/loaders/grub-x86.efi downloading https://cobbler.github.io/loaders/grub-0.97-x86_64.efi to /var/lib/cobbler/loaders/grub-x86_64.efi *** TASK COMPLETE *** 添加rsync到自启动并启动rsync systemctl enable rsyncd systemctl start rsyncd 修改密码为123456 ，salt后面是常用的加盐方式加密 [root@cobbler ~]# openssl passwd -1 -salt '123456' '123456' $1$123456$wOSEtcyiP2N/IfIl15W6Z0 vim /etc/cobbler/settings # 修改settings配置文件中下面位置，把新生成的密码加进去 default_password_crypted: "$1$123456$wOSEtcyiP2N/IfIl15W6Z0 再次执行cobbler check[root@cobbler ~]# cobbler check The following are potential configuration items that you may want to fix: 1 : Some network boot-loaders are missing from /var/lib/cobbler/loaders. If you only want to handle x86/x86_64 netbooting, you may ensure that you have installed a *recent* version of the syslinux package installed and can ignore this message entirely. Files in this directory, should you want to support all architectures, should include pxelinux.0, menu.c32, elilo.efi, and yaboot. 2 : debmirror package is not installed, it will be required to manage debian deployments and repositories 3 : fencing tools were not found, and are required to use the (optional) power management features. install cman or fence-agents to use them Restart cobblerd and then run 'cobbler sync' to apply changes. ks#platform=x86, AMD64, or Intel EM64T #version=DEVEL # Install OS instead of upgrade install # Keyboard layouts keyboard 'us' # Root password rootpw --iscrypted $1$m1pE0DG6$vALBphGGynqvUzfJaWZ6U1 # Use network installation url --url="$tree" # System language lang en_US # Firewall configuration firewall --disabled # System authorization information auth --useshadow --passalgo=sha512 # Use graphical install graphical firstboot --disable # SELinux configuration selinux --disabled # Network information network --bootproto=dhcp --device=eth0 network --bootproto=dhcp --device=eth1 # Reboot after installation reboot # System timezone timezone Asia/Shanghai # System bootloader configuration bootloader --location=mbr # Clear the Master Boot Record zerombr # Partition clearing information clearpart --all --initlabel # Disk partitioning information part /boot --asprimary --fstype="ext4" --size=200 part / --fstype="ext4" --grow --size=1 %packages @base @core @compat-libraries @debugging @development @gnome-desktop @X Window System %end
